Empowering the High-Power Devices with Gigabit PoE++ Ports

Easily Build a Whole 10G Multi-gigabit Network

Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.

10G support	Yes
AC input frequency	50/60 Hz
AC input voltage	100 - 240 V
Access Control List (ACL)	Y
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Broadcast storm control	Y
Cables included	AC
Certification	CE, FCC, RoHS
Console port	RJ-45/micro-USB
Depth	330 mm
Flow control support	Y
Form factor	1U
Forwarding rate	95.23 Mpps
Head-of-line (HOL) blocking	Y
Heat dissipation	1658.78 BTU/h
Height	44 mm
IGMP snooping	Y
Jumbo frames support	Y
LED indicators	Y
Link aggregation	Y
MAC address filtering	Y
MAC address table	16000 entries
Multicast support	Y
Networking standards	IEEE 802.3af,IEEE 802.3at
Number of fans	3 fan(s)
Operating relative humidity (H-H)	10 - 90 %
Operating temperature (T-T)	0 - 40 °C
Packet buffer memory	12 MB
Port mirroring	Y
Power consumption (max)	486.2 W
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	16
Power source	AC
Power supply included	Y
Quality of Service (QoS) support	Y
Quick start guide	Y
Rack mounting	Yes
Rate limiting	Y
Reset button	Y
Spanning tree protocol	Y
SSH/SSL support	Y
Static port security	Y
Storage relative humidity (H-H)	5 - 90 %
Storage temperature (T-T)	-40 - 70 °C
Store-and-forward	Y
Switch layer	L2+
Switch type	Managed
Switching capacity	128 Gbit/s
System event log	Y
Total Power over Ethernet (PoE) budget	500 W
VLAN support	Y
Web-based management	Y
Width	440 mm
ARP inspection	Y
Jumbo frames	9000
IP-MAC-Port binding	Y
SFP+ module slots quantity	4
BPDU filtering/protection	Y
Authentication	Auto VLAN,Guest VLAN
Power over Ethernet (PoE) power per port	30 W
Power connector	AC-in jack
Configuring Location Settings (CLI)	Y
Product colour	Black
DHCP features	DHCP client,DHCP relay,DHCP server
Cloud-managed	Y
Power over Ethernet 4PPoE (PoE++) ports quantity	8
