Netgear GS724TP
  • Netgear GS724TP
  • Netgear GS724TP
  • Netgear GS724TP
  • Netgear GS724TP
Going Gigabit and PoE+ Just Got More Cost-Effective!

As a leading provider of network equipment for SMBs, NETGEAR understands the importance of providing great choice of PoE port counts and power budgets that can adapt to the business’s needs, whether in the hospitality, catering, education or retail domains.



The GS724TPv2 24-Port Gigabit Switch with PoE+ and 2 SFP Ports joins the NETGEAR Standalone Smart Managed Pro Switches family, adding full 24 port PoE+ support for deployment of modern high-power PoE devices. Cautious spender organizations can now deploy denser PoE+ devices connected to a cost-effective switch, with a reasonable PoE power budget of 190W.



NETGEAR Smart Managed Pro Switches offer powerful Layer 2 features, great PoE functionality, and enhanced performance and usability. These switches are the ideal solution even for the most advanced small and medium

rganizations looking for the best combination of features, performance, and value: they are purposely designed for converged networks where voice, video, data are all carried on a single network platform.



Temperature- and load-based fan-speed control combines accurate monitoring with minimized system acoustic noise: the GS724TPv2 supports quiet rack mounting operation with a maximum of 32.4dB even at full power and 25°C (77°F) ambient.
10G supportNo
AC input frequency50/60 Hz
AC input voltage100-240 V
Access Control List (ACL)Yes
Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Built-in processorYes
Cables includedAC
CertificationCE, FCC, VCCI, C-Tick
Colour of productBlack,Grey
DC-in jackYes
Depth257 mm
Firmware upgradeableYes
Flash memory32 MB
Form factor1U
Height43 mm
IGMP snoopingYes
Internal memory128 MB
Latency (1 Gbps)3.749 µs
LED indicatorsYes
MAC address table8000 entries
Mean time between failures (MTBF)165589 h
Multicast supportYes
Networking standardsIEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
Noise level32.4 dB
Number of multicast groups filtered128
Number of VLANs256
Operating altitude0 - 3000 m
Operating relative humidity (H-H)0 - 90 %
Operating temperature (T-T)0 - 50 °C
Packet buffer memory0.5 MB
Port mirroringYes
Power consumption (max)225 W
Power over Ethernet (PoE)Yes
Power over Ethernet plus (PoE+) ports quantity24
Processor frequency500 MHz
Quality of Service (QoS) supportYes
Rack mount kitYes
Rack mountingYes
Rubber feetYes
SafetyCE, cUL IEC950/EN60950
Spanning tree protocolYes
Storage relative humidity (H-H)0 - 95 %
Storage temperature (T-T)-20 - 70 °C
Switch layerL2/L3/L4
Switch typeManaged
Switching capacity52 Gbit/s
System event logYes
Total Power over Ethernet (PoE) budget192 W
User guideYes
Ventilation fan(s)2
VLAN supportYes
Web-based managementYes
Weight3700 g
Width440 mm
Access Control List (ACL) rules100
Installed SFP modules quantity2
Resource CDYes

GS724TP-200EUS.pdf

Netgear GS724TP Data Sheet

Download (442.62k)
