Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.



Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core's temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limits.



Intel® Demand Based Switching is a power-management technology in which the applied voltage and clock speed of a microprocessor are kept at the minimum necessary levels until more processing power is required. This technology was introduced as Intel SpeedStep® Technology in the server marketplace.
Bus typeQPI
CPU configuration (max)1
Embedded options availableN
Enhanced Intel SpeedStep TechnologyY
Execute Disable BitY
Idle StatesY
Intel 64Y
Intel Demand Based SwitchingY
Intel Enhanced Halt StateY
Intel Flex Memory AccessN
Intel Trusted Execution TechnologyY
Intel TSX-NIY
Intel Virtualization Technology for Directed I/O (VT-d)Y
Intel VT-x with Extended Page Tables (EPT)Y
Maximum internal memory524288 MB
Maximum number of PCI Express lanes48
PCI Express configurations1x16,1x4,1x8
PCI Express slots version3.0
Physical Address Extension (PAE)46 bit
Processor boost frequency4.30 GHz
Processor cache19456 KB
Processor codenameSkylake
Processor cores14
Processor frequency2.50 GHz
Processor lithography14 nm
Processor modelW-2175
Processor socketLGA 2066
Processor threads28
Product type4
Scalability1S
Supported instruction setsAVX,AVX 2.0,AVX-512,SSE4.2
Thermal Design Power (TDP)140 W
Thermal Monitoring TechnologiesY
Maximum internal memory supported by processor512 GB
Memory types supported by processorDDR4-SDRAM
Memory clock speeds supported by processor1600,1866,2133,2400,2666 MHz
Memory bandwidth supported by processor (max)85.3 GB/s
Memory channels supported by processorQuad
ECC supported by processorY
Intel Virtualization Technology (VT-x)Y
Processor package size45 x 52.5 mm
Market segmentSRV
StatusLaunched
Conflict Free processorY
Product familyIntel Xeon Processors
Intel® vPro™ TechnologyY
Intel® AES New Instructions (Intel® AES-NI)Y
Intel® Hyper Threading Technology (Intel® HT Technology)Y
Intel® Identity Protection Technology (Intel® IPT)Y
Intel® Turbo Boost Technology2.0
Processor ARK ID130046
Intel Turbo Boost Max Technology 3.0N
Intel® Optane™ Memory ReadyN
Intel® Speed Shift TechnologyY
AVX-512 Fused Multiply-Add (FMA) units2

Similar products

  • Intel Intel® Xeon® Processor E3-1275 v3 (8M Cache, 3.50 GHz)
    Intel Intel® Xeon® Processor E3-1275 v3...
  • Intel Intel® Xeon® Processor E3-1280 v3 (8M Cache, 3.60 GHz)
    Intel Intel® Xeon® Processor E3-1280 v3...
  • Intel Intel® Xeon® Processor E3-1270 v3 (8M Cache, 3.50 GHz)
    Intel Intel® Xeon® Processor E3-1270 v3...
  • Intel Intel® Xeon® Processor E3-1240 v3 (8M Cache, 3.40 GHz)
    Intel Intel® Xeon® Processor E3-1240 v3...
  • Intel Intel® Xeon® Processor E3-1230 v3 (8M Cache, 3.30 GHz)
    Intel Intel® Xeon® Processor E3-1230 v3...

Intel W-2175

Intel® Xeon® W-2175 Processor
(19.25M Cache, 2.50 GHz)

CD8067303842300

Out of Stock

£2,250.73
£1,875.61 Ex VAT.
