Intel E5-2699 v3
  • Intel E5-2699 v3
  • Intel E5-2699 v3
  • Intel E5-2699 v3
  • Intel E5-2699 v3
Servers, workstations, and storage solutions based on the new Intel® Xeon® processor E5 family deliver the best combination of performance, built-in capabilities, and cost-effectiveness to make data centers more flexible and efficient. From virtualization and cloud computing solutions to design automation or real-time financial transactions, you’ll be delighted by better than ever performance no matter what tasks you face.



Your investment in industry standard technology from Intel combined with innovative solutions from partners help future-proof your data center with infrastructure that grows with your business.



Technology to scale innovative private cloud services

Today’s private clouds enable greater business agility and efficiency by delivering innovative and scalable services that drive value back into the organizations they serve. Building and managing these services require systems that scale to meet your ever changing needs, while delivering solutions to the challenges IT managers face every day. Server and storage platforms based on the Intel® Xeon® processor E5 family are built to be at the heart of today’s data centers and enable powerful, versatile private cloud solutions.



New Intel® Xeon® processor E5: a new performance sweet spot

The Intel® Xeon® processor E5 family support key cloud requirements that make your data center agile and more responsive to changing business needs. Maintaining industry leadership for power efficiency and continuing Intel Xeon processor performance advancements, the Intel® Xeon® processor E5 family gives you additional performance when you need it for single- and multi-threaded applications, including increased floating-point performance for technical computing workloads.
BoxNo
Bus typeQPI
Component forserver/workstation
CPU configuration (max)2
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel AES New InstructionsYes
Intel Demand Based SwitchingYes
Intel Enhanced Halt StateYes
Intel Flex Memory AccessNo
Intel Hyper-Threading TechnologyYes
Intel Identity Protection TechnologyNo
Intel Secure KeyYes
Intel Smart CacheYes
Intel Trusted Execution TechnologyYes
Intel TSX-NINo
Intel Turbo Boost Technology2.0
Intel Virtualization TechnologyVT-d,VT-x
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel vPro TechnologyYes
Intel VT-x with Extended Page Tables (EPT)Yes
L3 cache speed2.3 GHz
Maximum number of PCI Express lanes40
Number of QPI links2
On-board graphics adapterNo
OS GuardYes
PCI Express configurations
PCI Express slots version3.0
Physical Address Extension (PAE)Yes
Processor boost frequency3.6 GHz
Processor cache45 MB
Processor codeSR1XD
Processor cores18
Processor familyIntel Xeon E5 v3
Processor frequency2.3 GHz
Processor lithography22 nm
Processor modelE5-2699V3
Processor operating modes64-bit
Processor socketLGA 2011-v3
Processor threads36
Scalability2S
SteppingC1
Supported instruction setsAVX
System bus rate9.6 GT/s
Tcase76.4 °C
Thermal Design Power (TDP)145 W
Thermal Monitoring TechnologiesYes
VID Voltage Range0.65 - 1.3 V
Processor cache typeL3
Maximum internal memory supported by processor768 GB
Memory types supported by processorDDR4-SDRAM
Memory clock speeds supported by processor1600,1866,2133 MHz
Memory bandwidth supported by processor (max)68 GB/s
Memory channels supported by processorQuad
ECC supported by processorYes
Intel Virtualization Technology (VT-x)Yes
Processor package size52.5 mm

CM8064401739300.pdf

Intel E5-2699 v3 Data Sheet

Download (2.77M)
