Box | N |
Bus type | QPI |
Component for | server/workstation |
CPU configuration (max) | 1 |
Embedded options available | N |
Enhanced Intel SpeedStep Technology | Y |
Execute Disable Bit | Y |
Idle States | Y |
Intel 64 | Y |
Intel Demand Based Switching | Y |
Intel Enhanced Halt State | Y |
Intel Flex Memory Access | N |
Intel Trusted Execution Technology | Y |
Intel TSX-NI | Y |
Intel Virtualization Technology for Directed I/O (VT-d) | Y |
Intel VT-x with Extended Page Tables (EPT) | Y |
Maximum internal memory | 524288 MB |
Maximum number of PCI Express lanes | 48 |
On-board graphics adapter | N |
PCI Express configurations | 1x16,1x4,1x8 |
PCI Express slots version | 3.0 |
Physical Address Extension (PAE) | 46 bit |
Processor boost frequency | 3.90 GHz |
Processor cache | 8448 KB |
Processor code | SR3LL |
Processor codename | Skylake |
Processor cores | 6 |
Processor family | Intel Xeon |
Processor frequency | 3.60 GHz |
Processor lithography | 14 nm |
Processor model | W-2133 |
Processor operating modes | 64-bit |
Processor socket | LGA 2066 |
Processor threads | 12 |
Product type | 4 |
Scalability | 1S |
Stepping | U0 |
Supported instruction sets | AVX,AVX 2.0,AVX-512,SSE4.2 |
Tcase | 65 °C |
Thermal Design Power (TDP) | 140 W |
Thermal Monitoring Technologies | Y |
Maximum internal memory supported by processor | 512 GB |
Memory types supported by processor | DDR4-SDRAM |
Memory clock speeds supported by processor | 1600,1866,2133,2400,2666 MHz |
Memory bandwidth supported by processor (max) | 85.3 GB/s |
Memory channels supported by processor | Quad |
ECC supported by processor | Y |
Intel Virtualization Technology (VT-x) | Y |
Processor package size | 45 x 52.5 mm |
Status | Launched |
Intel Software Guard Extensions (Intel SGX) | Y |
Conflict Free processor | Y |
Product family | Intel Xeon Processors |
Intel® vPro™ Technology | Y |
Intel® AES New Instructions (Intel® AES-NI) | Y |
Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
Intel® Identity Protection Technology (Intel® IPT) | Y |
Intel® Secure Key | Y |
Intel® OS Guard | Y |
Intel® Turbo Boost Technology | 2.0 |
Processor ARK ID | 125040 |
Intel Turbo Boost Max Technology 3.0 | N |
Intel® Optane™ Memory Ready | N |
Cooler included | N |
Intel® Speed Shift Technology | Y |
Intel® Memory Protection Extensions (Intel® MPX) | Y |
Intel® Device Protection Technology (Intel® DPT) with Boot Guard | Y |
Intel® Xeon® Processor W-2133
(8.25M Cache, 3.60 GHz)
CD8067303533204
