Intel E5-2630 v3
Intel® Turbo Boost Technology

Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.



Intel® Hyper-Threading Technology

Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.



Enhanced Intel SpeedStep® Technology

Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
BoxNo
Bus typeQPI
Component forserver/workstation
CPU configuration (max)2
ECCYes
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel AES New InstructionsYes
Intel Demand Based SwitchingYes
Intel Flex Memory AccessNo
Intel Hyper-Threading TechnologyYes
Intel Identity Protection TechnologyNo
Intel Secure KeyYes
Intel Trusted Execution TechnologyYes
Intel TSX-NINo
Intel Virtualization TechnologyVT-d, VT-x
Intel vPro TechnologyYes
Intel VT-x with Extended Page Tables (EPT)Yes
Memory bandwidth (max)59 GB/s
Memory channelsQuad
Number of QPI links2
OS GuardYes
PCI Express configurations1x4, 1x8, 1x16
Processor boost frequency3.2 GHz
Processor cores8
Processor familyIntel Xeon
Processor frequency2.4 GHz
Processor lithography22 nm
Processor modelE5-2630V3
Processor socketLGA 2011-v3
Processor threads16
Supported instruction setsAVX 2.0
Supported memory clock speeds1600, 1866 MHz
System bus rate8 GT/s
Thermal Monitoring TechnologiesYes
VID Voltage Range0.65 - 1.30 V

Similar products

  • Intel Intel® Xeon® Processor E3-1275 v3 (8M Cache, 3.50 GHz)
    Intel Intel® Xeon® Processor E3-1275 v3...
  • Intel Intel® Xeon® Processor E3-1280 v3 (8M Cache, 3.60 GHz)
    Intel Intel® Xeon® Processor E3-1280 v3...
  • Intel Intel® Xeon® Processor E3-1270 v3 (8M Cache, 3.50 GHz)
    Intel Intel® Xeon® Processor E3-1270 v3...
  • Intel Intel® Xeon® Processor E3-1240 v3 (8M Cache, 3.40 GHz)
    Intel Intel® Xeon® Processor E3-1240 v3...
  • Intel Intel® Xeon® Processor E3-1230 v3 (8M Cache, 3.30 GHz)
    Intel Intel® Xeon® Processor E3-1230 v3...

Intel Intel® Xeon® Processor E5-2630 v3 (20M Cache, 2.40 GHz)

Intel® Xeon® Processor E5-2630 v3
(20M Cache, 2.40 GHz)

CM8064401831000

Out of Stock

£770.44
£642.04 Ex VAT.
