Create a dual-monitor workstation using your laptop, adding two 4K Ultra HD displays and Gigabit Ethernet

This USB to dual DisplayPort mini docking station makes it easy to create a high-performance dual-4K workstation, connecting your MacBook or Windows laptop to two DisplayPort monitors plus Gigabit Ethernet wired network. The dock features a compact design that's perfect for business professionals who need a highly functional workstation when working or traveling between multiple office locations, or when using shared workspaces.

Enhance your productivity with two 4K monitors

The mini docking station lets you transform your laptop into a highly productive workstation, by expanding the display capabilities of your laptop across two Ultra HD 4K monitors, even if your laptop video card doesn't natively support it. The USB 3.0 docking station supports low-latency, high-resolution 4K graphics on both video ports, using DisplayPort monitors. It works with any laptop that has an available USB 3.0 (USB-A) port.

The mini dock supports DisplayLink graphics technology, with the DisplayLink-6950 chipset, to provide support for dual 4Kp60 displays. With the dual-4K mini dock, you can connect:

2x 4K DisplayPort displays at 4096 x 2160 resolution @ 60Hz / 3840 x 2160 @ 60Hz

Single 5K display at 5120 × 2880 @ 60Hz

The mini docking station is ideal for producers, graphic and web designers, engineers, architects and many other professionals who work on advanced graphics applications. It offers a fast and easy way to maximize your laptop’s workable screen space, giving you three screens in total when coupled with your laptop’s display.

Easily adaptable to multiple workspaces

The mini dock’s compact size is ideal for business professionals working in space restricted workspaces or multiple locations, and require a high-performance dual-monitor workstation.

The Gigabit Ethernet port provides a reliable network connection in areas where Wi-Fi is limited or unavailable.

Effortless setup

The mini docking station ensures easy plug-and-play setup with no drivers required. It’s bus-powered from your laptop, so no external power adapter is required.

The USBA2DPGB is backed by a StarTech.com 3-year warranty and free lifetime technical support.

The StarTech.com Advantage

- Enhance your productivity by connecting your laptop to dual DisplayPort monitors, with 4K (3840 x 2160) resolution @ 60Hz in extended mode
- Mac and Windows compatible, works with any laptop with an available USB 3.0 (USB-A) port
- Compact, mini form factor for smaller work spaces and easy portability
Auto MDI/MDI-XY
Brand compatibilityUniversal
Cable length0.14 m
Card reader integratedN
CertificationCE, FCC
ChipsetDisplayLink - DL-6950
Colour of productBlack
Connectivity technologycable
Data transfer rate5 Gbit/s
Depth130 mm
DisplayPorts quantity2
Ethernet LANY
Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100,1000 Mbit/s
Full duplexY
Height20 mm
Host interfaceUSB 3.0 (3.1 Gen 1) Type-A
Mac compatibilityY
Mac operating systems supportedMac OS X 10.10 Yosemite,Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra
Maximum digital resolution4096 x 2160 pixels
Microphone inN
Networking standardsIEEE 802.3,IEEE 802.3ab,IEEE 802.3u
Number of displays supported2
Operating relative humidity (H-H)10 - 90 %
Operating temperature (T-T)0 - 40 °C
Package depth114 mm
Package height38 mm
Package weight215 g
Package width200 mm
Power source typeUSB
Quick start guideY
RoHS complianceY
Storage temperature (T-T)-10 - 60 °C
UASP supportN
Wake-on-LAN readyY
Weight126 g
Width58 mm
Windows operating systems supportedWindows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 Pro,Windows 10 Pro x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Win

USBA2DPGB.pdf

StarTech.com USB to Dual DisplayPort Mini Docking Station - Dual 4K 60Hz - GbE - USB 3.0 Data Sheet

Download (138.49k)
