AC input frequency | 50 - 60 Hz |
AC input voltage | 100-240 V |
Concurrent connections | 3000000 |
Connectivity technology | Wired |
Dimensions (WxDxH) | 429 x 502 x 44 mm |
Ethernet LAN (RJ-45) ports | 12 |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Firewall throughput | 20000 Mbit/s |
Form factor | 1U |
Input current | 6 A |
Maximum firewall connections per second | 75000 |
Noise level | 56 dB |
Non-operating altitude | 0 - 12192 m |
Number of hard drives installed | 1 |
Number of power supply units | 2 |
Number of VLANs | 1024 |
Operating altitude | 0 - 3048 m |
Operating relative humidity (H-H) | 10 - 85 % |
Operating temperature (T-T) | 0 - 40 °C |
Power supply | 400 W |
Rack mounting | Yes |
Serial ports quantity | 1 |
Storage relative humidity (H-H) | 5 - 95 % |
Storage temperature (T-T) | -20 - 65 °C |
Total storage capacity | 200 GB |
USB 2.0 ports quantity | 1 |
VPN throughput | 2000 Mbit/s |
Weight | 9530 g |
SFP+ module slots quantity | 4 |
Maximum Number of VPN connections supported | 10000 |
1RU, 12x 10M/100M/1GBASE-T, 4x 10G SPF+, USB 2.0, 20 Gbps, 44 x 429 x 502 mm
FPR2140-ASA-K9
