MAXIMIZE PERFORMANCE
WITH A MULTI-GIG NETGEAR PoE++ SWITCH
2.5Gbps Ethernet port with Ultra60 PoE++ enables the fastest connection between the access point and switch

MESH CAPABILITY
Create a scalable and seamless network for your business. All Insight Managed Cloud access points can be connected with Ethernet or mesh among themselves

NETGEAR INSIGHT REMOTE MANAGEMENT
Manage locally or remotely through the Cloud for simple yet powerful control of your network anytime, anywhere. Includes 1-year subscription.

MARKET LEADING SUPPORT FROM TRAINED EXPERTS
NETGEAR Access Points
include a market-leading 5-year warranty with 24/7 support from our highly trained experts.
Antenna gain level (max)2.9 dBi
Antenna typeinternal
Antennas quantity2
Auto MDI/MDI-XY
Cabling technology10/100/1000Base-T(X)
DC-in jackY
Depth239.6 mm
Ethernet LAN (RJ-45) ports2
Ethernet LAN data rates10,100,1000,2500 Mbit/s
Height51.38 mm
Input current2.5 A
LED indicatorsY
MAC address filteringY
Maximum data transfer rate5400 Mbit/s
Mounting kitY
Networking standardsIEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n
Number of products included1 pc(s)
Number of users275 user(s)
Operating relative humidity (H-H)0 - 40 %
PlacementCeiling,Wall
Power over Ethernet (PoE)Y
Quick start guideY
Reset buttonY
Security algorithmsEAP,PEAP,SSID,TLS,TTLS,WPA,WPA2,WPA3
Spread spectrum methodOFDM,OFDMA
VLAN supportY
Web-based managementY
Weight819 g
Width241.15 mm
2.4 GHzY
5 GHzY
Auto Wireless Distribution System (WDS)Y
DC voltage range12 V
MIMOY
MIMO typeMulti User MIMO
Product colourWhite
Service Set Identifier (SSID) featuresSSID broadcast,SSID broadcast on/off
Maximum data transfer rate (2.4 GHz)600 Mbit/s
Maximum data transfer rate (5 GHz)4800 Mbit/s
Remote Authentication Dial-In User Service (RADIUS)Y
Wi-Fi Multimedia (WMM)/(WME)Y

wax625-100eus.pdf

NETGEAR AX5400 Data Sheet

Download (1.45M)

Similar products

  • Netgear WA510
    Netgear WA510
  • Netgear WAX610
    Netgear WAX610
  • Netgear WAX610Y
    Netgear WAX610Y
  • Netgear WiFi 6 Orbi
    Netgear WiFi 6 Orbi
  • Netgear WAX620
    Netgear WAX620

NETGEAR AX5400

2.4GHz 802.11b/g/n/ax, 5.0GHz 802.11a/n/ac/ax, MU-MIMO, 5.4 Gbps, PoE, 241.15 x 239.6 x 51.38 mm, 819 g

wax625-100eus

Out of Stock

£327.18
£272.65 Ex VAT.
