The UniFi Switch 8-port models feature Gigabit Ethernet ports in a compact form factor. The switches are fully manageable, delivering robust performance and intelligent switching for your networks.



The US-8-60W is an 8-port gigabit switch with four 802.3af PoE ports. Its auto-sensing PoE ports deliver up to 15.4W of power per port.



Non-Blocking Throughput

The new 8-port models feature Gigabit Ethernet ports in a compact form factor. For its total, non-blocking throughput, each UniFi Switch supports up to 8 Gbps.



Switching Capacity

The UniFi Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss, with a switching capacity of 16 Gbps.



Seamless Integration

A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.
10G supportNo
Auto-sensingY
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Broadcast storm controlY
CertificationETSI300-019-1.4, CE, FCC, IC
Colour of productGrey
Depth99.5 mm
Flow control supportY
Height30.7 mm
Housing materialSteel
Jumbo frames supportY
LED indicatorsActivity,Link,PoE,Speed
Networking standardsIEEE 802.1x,IEEE 802.3af
Operating relative humidity (H-H)5 - 95 %
Operating temperature (T-T)-5 - 45 °C
Output current1.25 A
Output voltage48 V
Port mirroringY
Power consumption (max)12 W
Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity4
Quick start guideY
Reset buttonY
Spanning tree protocolY
Switch typeManaged
Switching capacity16 Gbit/s
Throughput8000 Mpps
Total Power over Ethernet (PoE) budget60 W
VLAN supportY
Wall mountableY
Web-based managementY
Weight432 g
Width148 mm
Power over Ethernet (PoE) power per port15.4 W
Power over Ethernet (PoE) voltage range57 - 44 V
Power connectorDC-in jack

US-8-60W-5.pdf

Ubiquiti Networks 5 x Switch 8 Data Sheet

Download (5.99M)
