More Info
Details
Spec Sheet

AC input frequency	50/60 Hz
AC input voltage	100-240 V
Access Control List (ACL)	Y
Backup features	Cloud,iSCSI LUN
Backup function	Y
Browser supported	Chrome, Firefox, Internet Explorer 10+, Safari 10+
Cables included	AC
Certification	EAC, VCCI, RCM, FCC, CE, BSMI
Chassis type	Rack (2U)
Cooling type	active
Depth	297.6 mm
Device class	Small & Medium Business
Embedded options available	Y
eSATA ports quantity	1
Ethernet LAN	Y
Ethernet LAN (RJ-45) ports	4
Ethernet LAN data rates	10,100,1000 Mbit/s
Execute Disable Bit	N
Fan diameter	80 mm
Graphics & IMC lithography	22 nm
Height	88 mm
Hot-swap drive bays	Y
Installed storage drive type	N
Intel 64	Y
Intel VT-x with Extended Page Tables (EPT)	Y
Internal memory	2 GB
Internal memory type	DDR3
iSCSI support	Y
LED indicators	Alarm,HDD,Power,Status
Link aggregation	Y
Mac operating systems supported	Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.13 High Sierra
Maximum number of PCI Express lanes	16
Maximum RAM supported	16 GB
Memory slots	2
Multilingual support	Y
Noise level	36.8 dB
Number of fans	2 fan(s)
Number of power supply units	1
Number of storage drives supported	8
Number of users	2048 user(s)
On/off switch	Y
Operating relative humidity (H-H)	5 - 95 %
Operating system installed	DiskStation Manager
Operating temperature (T-T)	5 - 35 °C
PCI Express slots version	2.0
Physical Address Extension (PAE)	Y
Power consumption (typical)	60.31 W
Power supply location	Built-in
Power supply unit (PSU) capacity	250 W
Processor cache	2 MB
Processor code	SR1S9
Processor cores	4
Processor family	Intel Atom
Processor frequency	2.4 GHz
Processor lithography	22 nm
Processor model	C2538
Processor operating modes	32-bit,64-bit
Processor socket	BGA 1283
Processor threads	4
Quick installation guide	Y
RAID levels	0,1,5,6,10,JBOD
RAID support	Y
Reset button	Y
RoHS compliance	Y
Server operating systems supported	Windows Server 2012,Windows Server 2012 R2,Windows Server 2016
Stepping	B0
Storage drive sizes supported	2.5,3.5 "
Storage drives installed	N
Storage temperature (T-T)	-20 - 60 °C
Supported file systems	BTRFS,FAT,HFS+,NTFS,ext3,ext4
Supported network protocols	CIFS, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN, L2TP)
Supported storage drive interfaces	Serial ATA
Supported storage drive types	HDD,SSD
Thermal Design Power (TDP)	15 W
Type	NAS
UART	Y
USB port	Y
Wake-on-LAN ready	Y
Web-based management	Y
Weight	6900 g
Wi-Fi	No
Width	430.5 mm
Windows operating systems supported	Windows 10,Windows 7
Processor cache type	L3
Maximum internal memory supported by processor	64 GB
Memory types supported by processor	DDR3-SDRAM,DDR3L-SDRAM
Memory channels supported by processor	Dual
ECC supported by processor	Y
Intel Virtualization Technology (VT-x)	Y
Processor package size	34 mm
USB 3.0 (3.1 Gen 1) Type-A ports quantity	2
Conflict Free processor	N
S.M.A.R.T. support	Y
Digital Living Network Alliance (DLNA) certified	Y
Intel® AES New Instructions (Intel® AES-NI)	Y
Intel® Hyper Threading Technology (Intel® HT Technology)	N
Intel® Turbo Boost Technology	N
Processor ARK ID	77981
System log	Y
Intel QuickAssist Technology	Y
Online RAID migration	Y
Online RAID expansion	Y
Power consumption (HDD standby)	29.04 W
Product colour	Black
