Certification | FCC Part 15 (Class A), CE EMC (Class A), C-Tick (Class A), BSMI, LVD (EN60950-1), BSMI |
Connectivity technology | Wired |
Content filtering | 1 |
Dimensions (WxDxH) | 300 x 188 x 44 mm |
Ethernet LAN (RJ-45) ports | 7 |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Firewall throughput | 2600 Mbit/s |
Form factor | Desktop |
Heat dissipation | 82.23 BTU/h |
Input current | 4.17 A |
Mean time between failures (MTBF) | 529688.2 h |
Number of VLANs | 64 |
Operating relative humidity (H-H) | 10 - 90 % |
Operating temperature (T-T) | 0 - 40 °C |
Package depth | 152 mm |
Package height | 245 mm |
Package weight | 2830 g |
Package width | 351 mm |
Power consumption (max) | 24.1 W |
Rack mounting | Yes |
Storage relative humidity (H-H) | 10 - 90 % |
Storage temperature (T-T) | -30 - 70 °C |
VPN throughput | 900 Mbit/s |
Weight | 1650 g |
USB 3.0 (3.1 Gen 1) Type-A ports quantity | 2 |
Active TCP connections (max) | 1000000 |
2600 Mbps, 1000000 TCP, 10/100/1000 Mbps, 7x Ethernet, 2x USB 3.0, DB9, 300x188x44 mm
ATP500-EU0102F
Out of Stock
