| Bluetooth | Yes |
| Bluetooth version | 4.1 |
| Bus type | DMI3 |
| Cabling technology | 10/100/1000Base-T(X) |
| Chassis type | SFF |
| Colour of product | Black |
| CPU configuration (max) | 1 |
| Depth | 290.5 mm |
| DisplayPorts quantity | 2 |
| Embedded options available | No |
| Energy Star certified | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Execute Disable Bit | Yes |
| Hard drive capacity | 500 GB |
| Hard drive size | 3.5 " |
| Hard drive speed | 7200 RPM |
| Headphone outputs | 1 |
| Height | 343.5 mm |
| Housing material | Metal |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel TSX-NI | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Internal memory | 4 GB |
| Internal memory type | DDR4-SDRAM |
| Keyboard supplied | Yes |
| Line-in | Yes |
| Line-out | Yes |
| Maximum internal memory | 64 GB |
| Maximum number of PCI Express lanes | 16 |
| Memory slots | 4x DIMM |
| Microphone in | Yes |
| Motherboard chipset | Intel Q270 |
| Mouse included | Yes |
| Non-ECC | Yes |
| Number of hard drives installed | 1 |
| Number of processors installed | 1 |
| Number of storage drives installed | 1 |
| On-board graphics adapter | Yes |
| On-board graphics adapter model | Intel HD Graphics 630 |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 10 Pro |
| Optical drive type | DVD±RW |
| Optical drives quantity | 1 |
| PCI Express configurations | 1x16,1x8+2x4,2x8 |
| PCI Express slots version | 3.0 |
| Placement supported | Horizontal/Vertical |
| Power supply | 210 W |
| Processor boost frequency | 3.8 GHz |
| Processor cache | 6 MB |
| Processor code | SR335 |
| Processor codename | Kaby Lake |
| Processor cores | 4 |
| Processor family | Intel Core i5-7xxx |
| Processor frequency | 3.4 GHz |
| Processor lithography | 14 nm |
| Processor model | i5-7500 |
| Processor operating modes | 64-bit |
| Processor socket | LGA 1151 (Socket H4) |
| Processor threads | 4 |
| Product type | PC |
| RoHS compliance | Yes |
| Scalability | 1S |
| Stepping | B0 |
| Storage media | HDD |
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
| System bus rate | 8 GT/s |
| Thermal Design Power (TDP) | 65 W |
| Thermal Monitoring Technologies | Yes |
| Thermal solution specification | PCG 2015C |
| Tjunction | 100 °C |
| Total storage capacity | 500 GB |
| VGA (D-Sub) ports quantity | 1 |
| Weight | 5400 g |
| Wi-Fi | Yes |
| Wi-Fi standards | IEEE 802.11ac |
| Width | 92.5 mm |
| Processor cache type | Smart Cache |
| Maximum internal memory supported by processor | 64 GB |
| Memory types supported by processor | DDR3L-SDRAM,DDR4-SDRAM |
| Memory clock speeds supported by processor | 1333,1600,2133,2400 MHz |
| Memory channels supported by processor | Dual |
| ECC supported by processor | No |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Clear Video Technology | Yes |
| Memory voltage supported by processor | 1.35 V |
| Processor package size | 37.5 x 37.5 mm |
| On-board graphics adapter base frequency | 350 Mhz |
| On-board graphics adapter dynamic frequency (max) | 1100 MHz |
| Maximum on-board graphics adapter memory | 64 GB |
| On-board graphics adapter DirectX version | 12.0 |
| On-board graphics adapter OpenGL version | 4.4 |
| Processor series | Intel Core i5-7500 Desktop Series |
| On-board graphics adapter ID | 5912 |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 8 |
| Conflict Free processor | Yes |
| Number of displays supported (on-board graphics) | 3 |
| Intel segment tagging | Enterprise,Professional |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Secure Key | Yes |
| Intel® OS Guard | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Quick Sync Video Technology | Yes |
| Processor ARK ID | 97123 |
| Intel® InTru™ 3D Technology | Yes |
