APC AP4422
  • APC AP4422
  • APC AP4422
  • APC AP4422
  • APC AP4422
Provides redundant rack mount power to single-corded equipment.



10 kAIC Overcurrent Protection

Provides protection in the event of a significant overcurrent event.



Command line interface

Offers simultaneous remote management access through Telnet and SSH



Current Monitoring

Monitors the aggregate current draw per power distribution unit.



Cyber security

A cyber-secure connection provides improved security for your infrastructure devices, and machine data forms the basis of operational insights and analytics, aimed at reducing equipment maintenance costs.



Quick Transfer Rate

Transfer rate is within the industry standard and within the time power supplies will typically drop loads. The transfer of one power source to another is seamless to the connected equipment avoiding disruption of equipment performance.



Remote Management Capabilities

Full-featured network management interfaces that provide standards-based management via Web, SNMP, and Telnet. Allows users to access, configure, and manage units from remote locations to save valuable time. Associated with this feature is the ability to quickly and easily upgrade the firmware via network download to installed units for future product enhancements.



RoHS

Certifies that electronic devices don't contain hazardous metals and flame retardants



StruxureWare Data Center Expert compatible

Enables centralized management via StruxureWare Data Center Expert.
AC outlets quantity2 AC outlet(s)
Cable length0.91 m
Colour of productBlack
Dimensions (WxDxH)432 x 236 x 44 mm
DisplayLCD
Input connection typeIEC 309 16A 2P+E
Input frequency50/60 Hz
Load capacity3840 VA
Maximum current16 A
MountingHorizontal
Nominal input voltage230 V
Nominal output voltage230 V
Non-operating altitude0 - 15000 m
Operating altitude0 - 3000 m
Operating relative humidity (H-H)0 - 95 %
Operating temperature (T-T)-5 - 45 °C
Output connectionsIEC 309 16A 2P+E
Package depth349 mm
Package dimensions (WxDxH)600 x 349 x 114 mm
Package height114 mm
Package weight5950 g
Package width600 mm
PDU typesSwitched
Rack mounting1U
RoHS complianceY
Storage relative humidity (H-H)0 - 95 %
Storage temperature (T-T)-25 - 65 °C
Supported network protocolsSNMP, Telnet, SSH
USB ports quantity1
Weight4210 g

AP4422.pdf

APC AP4422 Data Sheet

Download (72.97k)

Similar products

  • APC Service Bypass PDU
    APC Service Bypass PDU
  • APC Service Bypass PDU 230V 16AMP W/ (6) IEC C13 And (1) C19
    APC Service Bypass PDU 230V 16AMP W/ (6)...
  • APC In-Line Current Meter, 16A, 230V, IEC309-16A, 2P+G
    APC In-Line Current Meter, 16A, 230V,...
  • APC In-Line Current Meter
    APC In-Line Current Meter
  • APC SBPAR10K20H-WP
    APC SBPAR10K20H-WP

APC AP4422

Rack ATS, 230V, 16A, (2) IEC 309 in, (1) IEC 309 out

AP4422

Out of Stock

£11,118.26
£9,265.22 Ex VAT.
