Certification | UL 60950-1\nCAN/CSA-C22.2 No. 60950-1\nUL 2043\nIEC 60950-1\nEN 60950-1\nEN 50155 |
Channels quantity | 32 channels |
Colour of product | White |
Data transfer rate (max) | 1000 Mbit/s |
Depth | 51 mm |
Ethernet LAN (RJ-45) ports | 2 |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Flash memory | 64 MB |
Frequency band | 2.412 - 2.462, 5.18 - 5.32, 5.5 - 5.7, 5.745 - 5.825 GHz |
Height | 221 mm |
Housing material | Plastic |
Input voltage | 44 - 57 V |
Internal | N |
Internal memory | 512 MB |
LED indicators | Y |
Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11d,IEEE 802.11g,IEEE 802.11h,IEEE 802.11i,IEEE 802.11n,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u |
Non-operating altitude | 0 - 4500 m |
Operating altitude | 0 - 3000 m |
Operating relative humidity (H-H) | 10 - 90 % |
Operating temperature (T-T) | 0 - 40 °C |
Placement | Ceiling,Wall |
Power over Ethernet (PoE) | Yes |
Security algorithms | 802.1x RADIUS,AES,EAP,TKIP,WPA,WPA2 |
Storage temperature (T-T) | -30 - 70 °C |
Weight | 1000 g |
Wi-Fi data rate (max) | 867 Mbit/s |
Width | 221 mm |
2.4 GHz | Y |
5 GHz | Y |
Wi-Fi Multimedia (WMM)/(WME) | Y |
AIR-CAP1702I-B-K9 - Dual-band, controller-based 802.11a/g/n/ac, B - regulatory domain
AIR-CAP1702I-B-K9
Out of Stock
